7072E32 HEADLAMP HOLDER CROSSMEMBER - R.R.

Engines: 2.0 16V, 2.0 JTD 8V, 2.3 JTD 16V, 2.8 JTD 8V
Engines: 2.0 16V, 2.0 JTD 8V, 2.3 JTD 16V, 2.8 JTD 8V

RemovingManual illustration 20

RefittingManual illustration 21
Op. 7210E10 R.R. FRONT BUMPER Op. 7025A34 BONNET LID LOCK (ONE) - R+R OR REPAIR- Undo the bolts and fold the hose complete with cold air intake at the side.- Undo the bolts and place the power assisted steering fluid reservoir to the side. Op. 5540B10 EXTERIOR LIGHT DIMMER RESISTOR - R+RBoth sides1. Undo the radiator fixing bolts.
Manual illustration 244004760
Engines: 2.0 16V, 2.0 JTD 8V, 2.3 JTD 16V, 2.8 JTD 8V
- Fit a temporary bonnet lid stay.1. Remove the bonnet lid stay from the headlamp holder crossmember.
Manual illustration 244006324
Engines: 2.0 16V, 2.0 JTD 8V, 2.3 JTD 16V, 2.8 JTD 8V
1. Undo the bolts and nuts fixing the crossmember to the bodyshell.2. Remove the headlamp holder crossmember.
Manual illustration 244004762
Engines: 2.0 16V, 2.0 JTD 8V, 2.3 JTD 16V, 2.8 JTD 8V

RefittingManual illustration 21

RemovingManual illustration 20
- Fit the headlamp holder crossmember in position.- Tighten the bolts fixing the headlamp holder crossmember to the bodyshell.- Tighten the nuts fixing the headlamp holder crossmember to the bodyshell to torque.
[symbol: TORQUE 01.jpg]Value - daNmFasteningComponentØ
-2.9 daNmnutsM8
- Attach the bonnet lid stay.- Remove the temporary strut- Tighten the radiator fixing bolts. Op. 5540B10 EXTERIOR LIGHT DIMMER RESISTOR - R+RBoth sides- Reposition the bolts fixing the power assisted steering fluid reservoir and tighten them.- Reposition the bolts fixing hose complete with cold air intake and fasten them. Op. 7025A34 BONNET LID LOCK (ONE) - R+R OR REPAIR Op. 7210E10 R.R. FRONT BUMPER
